APPLICATIONS
For water supply from wells, tanks or reservoirs; For domestic use, for civil and industrial applications, for
garden use and irrigation, utilization of rain water.

OPERATING CONDITIONS
Water temperature upto 40°C
Maximum immersion depth: 20m
Maximum sand quantity into the water: 25g/m3

MOTOR AND MATERIALS
Degree of protection:  IP58
Insulation class:  B
External casing: AISI 304
Motor casing: AISI 304
Shaft: AISI 304
Impeller and diffuser, non-return valve: thermoplastic resin PPO
Outlet and Inlet: bronze

MOTOR:  adopts NEMA standard.

ACCESSORIES:
float switch, 20m PVC cable, control box with condenser etc.
